Global manufacturer of refrigerated display case
型号
外型尺寸(长*宽*高)
柜内温度(℃)
湿度范围
额定电压
制冷剂
整机功率(w)
JPZ1-1500ZJF
1500*850*1000
2~10/10~16
45%~55%
220V/50Hz
R404a/R134a
700
JPZ1-1800ZJF
1800*850*1000
2~10/10~16
45%~55%
220V/50Hz
R404a/R134a
850
JPZ1-2100ZJF
2100*850*1000
2~10/10~16
45%~55%
220V/50Hz
R404a/R134a
1100
JPZ1-2400ZJF
2400*850*1000
2~10/10~16
45%~55%
220V/50Hz
R404a/R134a
1300
产品主要性能介绍:
1、采用原装SECOP(思科普)压缩机(原丹佛斯Danfoss),静音稳定运行。
2、微电脑温度控制器、能准确控制柜内温度,带精准温度显示。
3、采用风冷循环制冷,加厚紫铜管制冷系统,经久耐用。
4、高清高透玻璃,视觉效果好。同时夹层加入电热丝,防止玻璃表面起雾结霜,保证较好展示效果;
5、主体能见面均采用201不锈钢材质,不锈钢螺丝,柜内能见面均为镜面不锈钢。
6、推拉门采用中空保温透明玻璃,四周轨道采用铝合金型材,静音流畅且经久耐用。
7、正面45度夹角单层展示,所有照明均为LED灯。
8、冷藏温度范围:2~10℃/10~16,控制湿度范围45%~55%。
9、一层展示底座为天然大理石装饰,颜色多色可选。
10、底部带轮,方便移动。
可定做移门式、抽屉式
(温馨提示:配置描述因产品升级或其他原因造成与实物不符,请以实物为准!)
1、Using original SECOP (Cisco Popular) compressor (original Danfoss), mute stable operation (mute design)。
2、The microcomputer temperature controller can accurately control the temperature inside the cabinet and display the temperature (outside the back of the cabinet).
3、Air cooled cycle refrigeration, thickened copper tube refrigeration system, durable。
4、Front arc glass adopts automatic electrothermal demister double hollow glass, which can automatically eliminate the water mist on the glass surface and ensure a better display effect; the side adopts hollow insulating transparent glass.。
5、201# stainless steel, stainless steel screws, and stainless steel can be used to meet the main body.。
6、The sliding door adopts hollow heat preservation transparent glass, and the surrounding rail adopts aluminum alloy profile (no fog proof function).。
7、Each floor is equipped with LED lights. The color of the tube is warm white. It is durable and safe.。
8、Refrigerating temperature range: +2 ~ +10 C, users can adjust the temperature range according to actual needs.。
9、On the second floor, the support of the frame is made of stainless steel with height adjusting holes. The height is adjustable (adjusting height is about 10 mm per knot). The frame is made of aluminum alloy, which is beautiful and generous.。
10、The base is decorated with natural marble. The colors are black gold sand, Indian red, golden thread beige, Phoenix jade white and violet red.。
11、Moving wheels at the bottom to facilitate movement. 。
